Size guide

Welcome to our guide on how to measure your external air conditioning unit to select the correct cover size. Choosing the right size is crucial to ensure a perfect fit and optimal protection of your air conditioner. In this guide, we will provide you with detailed instructions on how to take the correct measurements and give you useful tips to facilitate the process of selecting the ideal cover. With the right measurements in hand, you will be able to find the perfect cover for your air conditioning system's outdoor unit.

Wall installation

The most common type of installation for the outdoor air-conditioning unit is wall-mounted, where the unit is generally attached to the wall by brackets.

Misura la profondità della pompa di calore Mitsubishi PUHZ-SHW112YAA per scegliere un box antivento compatibile con installazione in giardino o cortile.

Width

Measure the width taking into account the protruding elements of the unit. Also pay special attention to the footprint of the pipes.

Dimensions pour cache mural Atlantic Extensa+ A.I., protège contre les intempéries et respecte l'esthétique extérieure.

Height

Measure the height from the top of the unit. It is not necessary to completely cover the brackets as the cover is open on the underside.

Frontansicht Vaillant VWL 105/6 A, zur Auswahl einer Schutzverkleidung, die sich in die Fassade integriert und Sichtbarkeit reduziert.

Depth

Measure the depth from the wall to the most protruding element. Usually, but not always, these are the support brackets.

Maximum dimensions for wall installation

Compare your measurements with the following table to choose the correct size

Size

Width (W)

Height (H)

Depth (D)

S

82cm

67cm

45–51cm

M

92cm

82cm

50–56cm

L

97cm

92cm

55–61cm

XL   (Big Blade)

107cm

92cm

57–63cm

XXL (Big Blade)

127cm

109cm

64–70cm

3XL (Big Blade)

142cm

109cm

74–80cm

VL   (Big Blade)

97cm

147cm

55–61cm

VXL (Big Blade)

125cm

169cm

64–70cm

On the floor, next to the wall

The external air-conditioning unit is positioned on the ground, in close proximity to the wall. The Cover Clima is installed against the wall and rests on the ground on a pair of adjustable feet.

Abmessungen Buderus WLW166i Wärmepumpe für Auswahl einer Wandverkleidung zum Schutz vor Regen und optischer Integration in die Fassade.

Width

Measure the width taking into account the protruding elements of the unit. Also pay special attention to the footprint of the pipes.

Come misurare la pompa Fujitsu WOYA060KLT per trovare un box estetico da parete che protegge dal sole e riduce il rumore.

Height

Measure the height from the floor to the roof of the unit. Remember that the adjustable floor feet add at least 8 cm to the height of the cover.

Measure your Alpha-Innotech LWD 90A to pick a cover that hides the unit, reduces noise and fits balconies or visible outdoor areas.

Depth

Measure the depth from the wall to the most prominent element. Usually, but not always, these are the floor supports.

Maximum dimensions for ground installation next to the wall

Compare the measurements taken with the following table to choose the correct size. These dimensions assume the use of a pair of adjustable ground feet at the front of the cover and wall attachment at the rear (already included with Big Blade)

Size

Width (W)

Height (H)

Depth (D)

S

82cm

74cm

45–51cm

M

92cm

91cm

50–56cm

L

97cm

101cm

55–61cm

XL   (Big Blade)

107cm

99cm

57–63cm

XXL (Big Blade)

127cm

116cm

64–70cm

3XL (Big Blade)

142cm

116cm

74–80cm

VL   (Big Blade)

97cm

154cm

55–61cm

VXL (Big Blade)

125cm

176cm

64–70cm

On the floor, freestanding

The external air conditioning unit is fixed to the ground and away from the wall. The Cover Clima is installed with 4 adjustable ground feet and a back panel.

Mesure frontale pour choisir un cache pompe à chaleur Viessmann 111.B06 qui respecte les normes et protège l’unité des intempéries.

Width

Measure the width taking into account the protruding elements of the unit. Also pay special attention to the footprint of the pipes.

Come misurare la pompa Fujitsu WOYA060KLT per trovare un box estetico da parete che protegge dal sole e riduce il rumore.

Height

Measure the height from the floor to the roof of the unit. Remember that the adjustable floor feet add at least 8 cm to the height of the cover.

Misure di una pompa di calore o climatizzatore esterno, per scegliere coperture antivento estetiche (modello: Mitsubishi PUHZ-SHW112YAA).

Depth

Measure the depth taking into account the protruding elements of the unit. Pay particular attention to the dimensions of the floor supports and pipes.

Maximum dimensions for freestanding installation

Compare the measurements taken with the following table to choose the correct size. These dimensions assume the use of four adjustable ground feet and the Blade or Curve back panel (panel and feet already included with Big Blade).

Size

Width (W)

Height (H)

Depth (D)

S

82cm

74cm

45cm

M

92cm

91cm

50cm

L

97cm

101cm

55cm

XL   (Big Blade)

107cm

99cm

57cm

XXL (Big Blade)

127cm

116cm

64cm

3XL (Big Blade)

142cm

116cm

74cm

VL   (Big Blade)

97cm

154cm

55cm

VXL (Big Blade)

125cm

176cm

64cm
